Gasoline & Diesel oil transfer pumps

Gasoline & Diesel oil transfer pumps have gear pump and centrifugal pump two kinds,centrifugal pump service life is longer.So we are mainly introduced centrifugal type gasoline transfer pump and diesel oil transfer pump.

Gasoline & Diesel oil transfer pump

Oil pump flow:0.6~800M3/H
Head:10-100M
Inlet/Outlet:1″ 2″ 3″ 4″ 6″ 8″ 10″ 12″ 14″
Application:Gasoline,diesel,kerosene transfer
Advantage:explosionproof
Model:CYB-S series

gasoline transfer pump Brief Introduction:
1.Gasoline & Diesel oil transfer pumps is one of the latest products in industrial oil transfer area. It is mainly used as a fuel off-loading pump to transfer fuel, such as diesel, kerosene, light oil,etc.
2. This pump is a horizontal self-priming oil pump, the head could reach 75 meters and the suction is between 5-6.5 meters.
3. It is usually worked in oil houses, gas stations, oil tankers, tank ships, docks, tank trucks and airports,etc.
4. The casing parts could be cast iron type or stainless steel type, and the impeller can be made of cast iron, stainless steel or bronze for different uses.

CYB-S Series Gasoline & Diesel oil transfer pumps flow and head data sheet

Model	Flow (m3/h)	Head (m)	Suction head (m)	Speed (r/min)	Self priming capacity (min/5m)	Power (kw)	Ports size(mm)
40CYB-S-40	10	40	6.5	2900	1.5	4	50
50CYB-S-12	15	12	6.5	2900	2.4	1.5	50
50CYB-S-20	18	20	6.5	2900	1.9	2.2	50
50CYB-S-30	20	30	6.5	2900	1.5	4	50
50CYB-S-35	14	35	6.5	2900	1.5	4	50
50CYB-S-40	10	40	6.5	2900	1.5	4	50
50CYB-S-50	12.5	50	6.5	2900	1.4	5.5	50
50CYB-S-65	15	60	6.5	2900	1.3	7.5	50
50CYB-S-75	20	75	6.5	2900	1.3	11	50
65CYB-S-15	30	15	6.5	2900	2	3	65
65CYB-S-32	25	32	6	2900	1.5	5.5	65
80CYB-S-13	35	13	6	2900	3.4	3	80
80CYB-S-17	43	17	6	2900	1.8	4	80
80CYB-S-22	40	22	6	2900	1.9	5.5	80
80CYB-S-25	50	25	6	2900	1.5	7.5	80
80CYB-S-32	50	32	6	2900	1.5	7.5	80
80CYB-S-55	60	55	6	2900	1.5	18.5	80
80CYB-S-70	60	70	6	2900	1.2	22	80
100CYB-S-20	100	20	6	2900	1.8	11	100
100CYB-S-40	100	40	6	2900	1.8	22	100
100CYB-S-40A	100	40	6	1450	1.5	22	100
100CYB-S-65	100	65	6	2900	1.8	30	100
100CYB-S-75	100	75	6	2900	1.8	30	100
150CYB-S-55	170	55	5	2900	1.8	45	150
150CYB-S-65	170	65	5	2900	1.3	55	150
150CYB-S-80	160	80	5	2900	1.2	55	150
200CYB-S-32	400	32	5	1450	2	55	200
200CYB-S-63	280	63	5	1450	1.5	90	200
200CYB-S-65	350	65	5	1450	1.5	75	250
250CYB-S-32	550	32	5	1450	2	90	250
250CYB-S-50	400	50	5	1450	2	90	250
300CYB-S-50	500	50	5	1450	2	110	300
250CYB-S-55	450	55	5	1450	2	110	250
250CYB-S-75	400	75	5	1450	1.5	132	250
300CYB-S-32	600	32	5	1450	2	90	300
300CYB-S-55	550	55	5	1450	2	132	300

Gasoline & Diesel Oil Transfer Pumps
