YHCB Explosion-proof Gear Pump is mainly used in conveying viscosity in 5 to 1500 CST, not containing solid particles, all kinds of liquid temperature does not exceed 80 degrees Celsius, such as gasoline, kerosene, diesel oil and mechanical lubricating oil. Is the ideal choice of the tanker and oil pump.
It is a special gear pump with high efficiency and energy saving.
It has the advantages of high flow rate, high pressure, small volume, low noise, low input speed, strong self-priming and convenient installation and maintenance.
| Model | Flow
Q(m 3 /h) |
Head
P(MPa) |
Speed
n(r/min) |
suction lift
(m) |
Motor | |
| Model | KW | |||||
| 50YHCB-8 | 8 | 0.4 | 960 | 5.5 | 132S-6 | 3 |
| 60YHCB-15 | 15 | 0.4 | 960 | 6 | 132M 1 -6 | 4 |
| 60YHCB-30 | 28 | 0.6 | 960 | 6 | 132M 2 -6 | 5.5 |
| 60YHCB-50 | 45 | 0.6 | 1430 | 6.5 | 132M-4 | 7.5 |
| 65YHCB-35 | 35 | 0.6 | 960 | 7 | 160M-6 | 7.5 |
| 76YHCB-40 | 40 | 0.6 | 960 | 7 | 160M-6 | 7.5 |
| 80YHCB-60 | 60 | 0.6 | 960 | 7 | 160L-6 | 11 |
| 80YHCB-80 | 80 | 0.4 | 960 | 6.5 | 180L-6 | 15 |
| 100YHCB-100 | 100 | 0.4 | 960 | 5.5 | 200L-6 | 22 |
| 125YHCB-150 | 150 | 0.4 | 960 | 5.5 | 250M-6 | 37 |
| 150YHCB-200 | 200 | 0.4 | 960 | 5.5 | 280M-6 | 55 |
